Spitzer/IRAC View of the Trifid Nebula
Ssc2005 02a3

Credit: NASA/JPL-Caltech/J. Rho (SSC/Caltech)

Observation • January 12th, 2005 • ssc2005-02a3

ssc2005-02a3

The glowing Trifid Nebula is revealed in an infrared view from NASA's Spitzer Space Telescope. The Trifid Nebula is a giant star-forming cloud of gas and dust located 5,400 light-years away in the constellation Sagittarius.The false-color Spitzer image reveals a different side of the Trifid Nebula. Where dark lanes of dust are visible trisecting the nebula in a visible-light picture, bright regions of star-forming activity are seen in the Spitzer picture. All together, Spitzer uncovered 30 massive embryonic stars and 120 smaller newborn stars throughout the Trifid Nebula, in both its dark lanes and luminous clouds. These stars are visible in the Spitzer image, mainly as yellow or red spots. Embryonic stars are developing stars about to burst into existence. Ten of the 30 massive embryos discovered by Spitzer were found in four dark cores, or stellar "incubators," where stars are born. Astronomers using data from the Institute of Radioastronomy millimeter telescope in Spain had previously identified these cores but thought they were not quite ripe for stars. Spitzer's highly sensitive infrared eyes were able to penetrate all four cores to reveal rapidly growing embryos.Astronomers can actually count the individual embryos tucked inside the cores by looking closely at this Spitzer image taken by its infrared array camera (IRAC). This instrument has the highest spatial resolution of Spitzer's imaging cameras. The embryos are thought to have been triggered by a massive "type O" star, which can be seen as a white spot at the center of the nebula. Type O stars are the most massive stars, ending their brief lives in explosive supernovas. The small newborn stars probably arose at the same time as the O star, and from the same original cloud of gas and dust.This Spitzer mosaic image uses data from IRAC showing light of 3.6 microns (blue), 4.5 microns (green), 5.8 microns (orange) and 8.0 microns (red).

About the Object

Name
Trifid NebulaMessier 20M20
Type
Nebula > Type > Star Formation
Star > Evolutionary Stage > Protostar
Distance
5,400 Light Years

Color Mapping

Band Wavelength Telescope
Infrared 3.6 µm Spitzer IRAC
Infrared 4.5 µm Spitzer IRAC
Infrared 5.8 µm Spitzer IRAC
Infrared 8.0 µm Spitzer IRAC

Astrometrics

Position (J2000)
RA =18h 2m 28.5s
Dec = -22° 58' 0.1"
Field of View
22.7 x 35.5 arcminutes
Orientation
North is 2.0° left of vertical
